Pensions Finder (Pensions Data Dashboard)
Welcome to the PTX Lab Pension Scheme pensions finder.
Using our Pensions Data Dashboard data model, we have created a concept for the Pensions Data Dashboard. This multi-step model mimics the user experience of searching for pensions with a provider, then the user can select which one they want further details on..
Process :
Step 1 - User enters their National Insurance Number (NINO), Date of birth (DOB) and Given/Family name. This is then converted into a Unique ID.
The system searches for the member using the Unique ID.
If the member is found, the a list of all pensions that the member has is returned in the form a Pension Identification Number (PeI) in addition to some individual member data and list of all pensions found.
Step 2 : User selects a Pension using the Pension Identification Number (PeI).
Pension, benefits and associated data is retrieved from the system and displayed to the user.
Step 1 - Enter your details to search and find if you have a pension in the PTX Lab Pension Scheme
Name of input
Value
Description
Date Of Birth
Enter DOB, Format DD/MM/YYYY
National Insurance number
Enter NINO - exclude last character
Given/Family Name
Enter given family name
Unique ID
-
Generated Unique ID, uses SHA256 Cryptography
Search not completed.
Developer Zone info
RunTime Information
Error message
Microservice not called
JSON text
---
Calculation audit
---
Function Information
Function name
PTX_Individual_PDP_UID and GetPensionDetails_PDP
Description
Pensions Dashboard Data 'Find' Individual Data Example and Get Pension details
API sample signature (new window)
Find individual details :
https://ptxapp.azurewebsites.net/api/FindIndividual_PDP/?GET&DOB=04/11/1986&NINO=ZZ420049&GivenName=SIZER
or
https://ptxapp.azurewebsites.net/api/FindIndividual_PDP/?GET&PTX_Individual_PDP_UID=27c02248c1e8245b05060f9324928b68832eabde01f7db31f59505128de0fb1f
Get Pensions details
https://ptxapp.azurewebsites.net/api/GetPensionDetails_PDP/?GET&PDP_PeI_Benefit=026e1bc873a9ab61b789cb912e6781d8759cb517b60e04008a462b8d0972676b
Inputs required
DOB [Date Of Birth, string DD/MM/YYYY],
GivenName [string],
NINOShort [NINO string]
OR
PTX_Individual_PDP_UID [String PTXSHA256].
PDP_PeI_Benefit [string/GUID relating to the the unique ID asscoated to the benefits.
Outputs
json, class : Individual_PDP, PDP formatted Individual class.
json, class : PDPPension, formatted Pension/Benefit class.
Version number
Beta V0.0.2 20210429
Technical notes
Based on documents on the Pension Dashboard document Dec 2020.
This is a simplified example.
As part of our analysis a complete relational data model has been designed, built and integrated in to our PTX.APP engine. Individual members and pension data is looked up by using a cryptographic unique ID. Also see the Encrypted Member Data WebApp.
